ATS SYSTEMS QUICK JAW CHANGE CHUCKS - MODEL B

Power Chucks : Ultimate Chuck™ Model UC2 B-Model

Model UC2B allows using existing custom wide top jaws

  • Optional master base jaws available to fit common serrated and T&G top jaws
  • Note: the High Performance jaw system of the UC2 is not available for the UC2B
  • Better for vertical lathes with O-ring seal to prevent coolant entering between drawtube and spindle bore
  • Full custom packages installed on your lathe by ATS engineers
  • Two year warranty with ATS installation
  • Womb-to-tomb support by local ATS Service Engineer
  • Optional High-Low hydraulic systems available
