- The Solution for First
Operation Chucking
- A few sets of jaws
quickly adjust to cover a wide diameter range
- Change, adjust or reverse all
three jaws in one minute
- 1/4 turn wrench, no T-nuts or
bolts
- Adjust hard jaws in and out to
any diameter
- Only three sets of "Deep Bite
Job Shop" hard jaws cover full grip range OD and ID
- Stop using inadequate grip
soft jaws for roughing operations
- "Deep Bite Job Shop Jaws"
transmit torque for maximum metal removal
- The Solution for Second
Operation Chucking
- Eliminate Soft Jaw
Reboring
- Save 45 minutes
of changeover downtime
- Bore jaws only once, store for
weeks or months, reinstall with 0.0005" TIR guaranteed
without reboring (7" to 12"
chucks, 16" chuck 0.0007" TIR)
|
- Monoblock Soft Jaws
- Double ended - bore each end
for a different part
- Premium alloy steel - lasts
much longer
- No bolts to interfere with
gripping surface
- Quick change
- Additional Benefits
- Ultimate Chuck™ wedge bar
design allows 25% higher spindle speeds
- Ultimate Chuck™
maintains 65% of starting grip force at maximum
rated RPM.
- Common chucks maintain
only 30% even at their lower rated RPM
- Full custom packages installed on
your lathe by ATS engineers
- Two year warranty with ATS
installation
- Womb-to-tomb support by local ATS
Service Engineer
- Optional High-Low hydraulic systems
available
|
